IO Crest Active HDMI to VGA Adapter with Audio Support via 3.5mm jack

Convert HDMI signals into VGA outputs at a maximum conversion rate of 200 MHz with IIS or SPDIF audio output. The HDMI Receiver integrated is compliant with HDMI 1.4b. The DACs are based on current source architecture. And the VGA output meet VESA VSIS v1r2 clock jitter target.

• Integrated EDID buffer
• VGA/HDMI connection detection supported
• On-chip encoder supports 2 channel IIS/S/PDIF audio output
• Supports VESA and CEA timing standards up to WUXGA 1920×1200@60MHz and 1920×1080@60MHz.
• Analog RGB output for VGA with Triple 9-bit DAC up to 200MHz pixel rate.
• Complaint with HDMI 1.4 specification
• Supports HDMI Standard Norm
